262
ATmega128(L)
2467B–09/01
123 PB4.Data Port B
122 PB4.Control
121 PB4.Pullup_Enable
120 PB5.Data
119 PB5.Control
118 PB5.Pullup_Enable
117 PB6.Data
116 PB6.Control
115 PB6.Pullup_Enable
114 PB7.Data
113 PB7.Control
112 PB7.Pullup_Enable
111 PG3.Data Port G
110 PG3.Control
109 PG3.Pullup_Enable
108 PG4.Data
107 PG4.Control
106 PG4.Pullup_Enable
105 TOSC 32 kHz Timer Oscillator
104 TOSCON
103 RSTT Reset Logic
(Observe-only)
102 RSTHV
101 EXTCLKEN Enable signals for main clock/oscillators
100 OSCON
99 RCOSCEN
98 OSC32EN
97 EXTCLK (XTAL1) Clock input and oscillators for the main clock
(Observe-only)
96 OSCCK
95 RCCK
94 OSC32CK
93 TWIEN TWI
Table 107. ATmega128 Boundary-scan Order (Continued)
Bit Number Signal Name Module
