135
ATmega128(L)
2467B–09/01
Extended Timer/Counter
Interrupt Mask Register –
ETIMSK
Note: This register is not available in ATmega103 compatibility mode.
• Bit 7:6 - Reserved Bits
These bits are reserved for future use. For ensuring compatibility with future devices,
these bits must be set to zero when ETIMSK is written.
• Bit 5 - TICIE3: Timer/Counter 3, Input Capture Interrupt Enable
When this bit is written to one, and the I-flag in the status register is set (interrupts glo-
bally enabled), the timer/counter 3 input capture interrupt is enabled. The corresponding
interrupt vector (
See “Interrupts” on page 54.) is executed when the ICF3 flag, located in
ETIFR, is set.
• Bit 4 - OCIE3A: Timer/Counter 3, Output Compare A Match Interrupt Enable
When this bit is written to one, and the I-flag in the status register is set (interrupts glo-
bally enabled), the timer/counter 3 output compare A match interrupt is enabled. The
corresponding interrupt vector (
See “Interrupts” on page 54.) is executed when the
OCF3A flag, located in ETIFR, is set.
• Bit 3 - OCIE3B: Timer/Counter 3, Output Compare B Match Interrupt Enable
When this bit is written to one, and the I-flag in the status register is set (interrupts glo-
bally enabled), the timer/counter 3 output compare B match interrupt is enabled. The
corresponding interrupt vector (
See “Interrupts” on page 54.) is executed when the
OCF3B flag, located in ETIFR, is set.
• Bit 2 - TOIE3: Timer/Counter 3, Overflow Interrupt Enable
When this bit is written to one, and the I-flag in the status register is set (interrupts glo-
bally enabled), the timer/counter 3 overflow interrupt is enabled. The corresponding
interrupt vector (
See “Interrupts” on page 54.) is executed when the TOV3 flag, located
in ETIFR, is set.
• Bit 1 - OCIE3C: Timer/Counter 3, Output Compare C Match Interrupt Enable
When this bit is written to one, and the I-flag in the status register is set (interrupts glo-
bally enabled), the timer/counter 3 output compare C match interrupt is enabled. The
corresponding interrupt vector (
See “Interrupts” on page 54.) is executed when the
OCF3C flag, located in ETIFR, is set.
• Bit 0 - OCIE1C: Timer/Counter 1, Output Compare C Match Interrupt Enable
When this bit is written to one, and the I-flag in the status register is set (interrupts glo-
bally enabled), the timer/counter 1 output compare C match interrupt is enabled. The
corresponding interrupt vector (
See “Interrupts” on page 54.) is executed when the
OCF1C flag, located in ETIFR, is set.
Bit 7 6 5 4 3 2 1 0
– – TICIE3 OCIE3A OCIE3B TOIE3 OCIE3C OCIE1C ETIMSK
Read/Write R R R/W R/W R/W R/W R/W R/W
Initial value 0 0 0 0 0 0 0 0
