57
ATmega162/V
2513E–AVR–09/03
Notes: 1. When the BOOTRST Fuse is programmed, the device will jump to the Boot Loader
address at reset, see “Boot Loader Support – Read-While-Write Self-programming”
on page 216.
2. When the IVSEL bit in GICR is set, Interrupt Vectors will be moved to the start of the
Boot Flash section. The address of each Interrupt Vector will then be the address in
this table added to the start address of the Boot Flash section.
Notes: 1. When the BOOTRST Fuse is programmed, the device will jump to the Boot Loader
address at reset, see “Boot Loader Support – Read-While-Write Self-programming”
on page 216.
2. When the IVSEL bit in GICR is set, Interrupt Vectors will be moved to the start of the
Boot Flash section. The address of each Interrupt Vector will then be the address in
this table added to the start address of the Boot Flash section.
Table 25. Reset and Interrupt Vectors if M161C is programmed
Vector No.
Program
Address (2) Source Interrupt Definition
1 0x000 (1) RESET External Pin, Power-on Reset, Brown-out
Reset, Watchdog Reset, and JTAG AVR
Reset
2 0x002 INT0 External Interrupt Request 0
3 0x004 INT1 External Interrupt Request 1
4 0x006 INT2 External Interrupt Request 2
5 0x008 TIMER2 COMP Timer/Counter2 Compare Match
6 0x00A TIMER2 OVF Timer/Counter2 Overflow
7 0x00C TIMER1 CAPT Timer/Counter1 Capture Event
8 0x00E TIMER1 COMPA Timer/Counter1 Compare Match A
9 0x010 TIMER1 COMPB Timer/Counter1 Compare Match B
10 0x012 TIMER1 OVF Timer/Counter1 Overflow
11 0x014 TIMER0 COMP Timer/Counter0 Compare Match
12 0x016 TIMER0 OVF Timer/Counter0 Overflow
13 0x018 SPI, STC Serial Transfer Complete
14 0x01A USART0, RXC USART0, Rx Complete
15 0x01C USART1, RXC USART1, Rx Complete
16 0x01E USART0, UDRE USART0 Data Register Empty
17 0x020 USART1, UDRE USART1 Data Register Empty
18 0x022 USART0, TXC USART0, Tx Complete
19 0x024 USART1, TXC USART1, Tx Complete
20 0x026 EE_RDY EEPROM Ready
21 0x028 ANA_COMP Analog Comparator
22 0x02A SPM_RDY Store Program Memory Ready
