• Bit 2:0 – CS02:0: Clock Select

The three Clock Select bits select the clock source to be used by the Timer/Counter.

If external pin modes are used for the Timer/Counter0, transitions on the T0 pin will
clock the counter even if the pin is configured as an output. This feature allows software
control of the counting.

Timer/Counter Register –
TCNT0

The Timer/Counter Register gives direct access, both for read and write operations, to
the Timer/Counter unit 8-bit counter. Writing to the TCNT0 Register blocks (removes)
the Compare Match on the following timer clock. Modifying the counter (TCNT0) while
the counter is running, introduces a risk of missing a Compare Match between TCNT0
and the OCR0 Register.

Output Compare Register –
OCR0

The Output Compare Register contains an 8-bit value that is continuously compared
with the counter value (TCNT0). A match can be used to generate an output compare
interrupt, or to generate a waveform output on the OC0 pin.

Timer/Counter Interrupt Mask
Register – TIMSK

• Bit 1 – TOIE0: Timer/Counter0 Overflow Interrupt Enable

When the TOIE0 bit is written to one, and the I-bit in the Status Register is set (one), the
Timer/Counter0 Overflow interrupt is enabled. The corresponding interrupt is executed if
an overflow in Tim er/Counter0 occurs, i.e., w hen the TOV0 bit is set in the
Timer/Counter Interrupt Flag Register – TIFR.

Table 51. Clock Select Bit Description

CS02

CS01

CS00

Description

0

0

0

No clock source (Timer/Counter stopped).

0

0

1

clk

I/O

/(No prescaling)

0

1

0

clk

I/O

/8 (From prescaler)

0

1

1

clk

I/O

/64 (From prescaler)

1

0

0

clk

I/O

/256 (From prescaler)

1

0

1

clk

I/O

/1024 (From prescaler)

1

1

0

External clock source on T0 pin. Clock on falling edge.

1

1

1

External clock source on T0 pin. Clock on rising edge.

Bit

7

6

5

4

3

2

1

0

TCNT0[7:0]

TCNT0

Read/Write

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

Initial Value

0

0

0

0

0

0

0

0

Bit

7

6

5

4

3

2

1

0

OCR0[7:0]

OCR0

Read/Write

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

Initial Value

0

0

0

0

0

0

0

0

Bit

7

6

5

4

3

2

1

0

TOIE1

OCIE1A

OCIE1B

OCIE2

TICIE1

TOIE2

TOIE0

OCIE0

TIMSK

Read/Write

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

Initial Value

0

0

0

0

0

0

0

0
