56

ATmega162/V

2513E–AVR–09/03

Interrupts

This section describes the specifics of the interrupt handling as performed in
ATmega162. For a general explanation of the AVR interrupt handling, refer to “Reset
and Interrupt Handling” on page 12.
Table 24 shows the interrupt table when the com-
patibility fuse (M161C) is unprogrammed, while Table 25 shows the interrupt table when
M161C Fuse is programmed. All assembly code examples in this sections are using the
interrupt table when the M161C Fuse is unprogrammed.

Interrupt Vectors in
ATmega162

Table 24. Reset and Interrupt Vectors if M161C is unprogrammed

Vector No.

Program

Address

(2)

Source

Interrupt Definition

1

0x000

(1)

RESET

External Pin, Power-on Reset, Brown-out
Reset, Watchdog Reset, and JTAG AVR
Reset

2

0x002

INT0

External Interrupt Request 0

3

0x004

INT1

External Interrupt Request 1

4

0x006

INT2

External Interrupt Request 2

5

0x008

PCINT0

Pin Change Interrupt Request 0

6

0x00A

PCINT1

Pin Change Interrupt Request 1

7

0x00C

TIMER3 CAPT

Timer/Counter3 Capture Event

8

0x00E

TIMER3 COMPA

Timer/Counter3 Compare Match A

9

0x010

TIMER3 COMPB

Timer/Counter3 Compare Match B

10

0x012

TIMER3 OVF

Timer/Counter3 Overflow

11

0x014

TIMER2 COMP

Timer/Counter2 Compare Match

12

0x016

TIMER2 OVF

Timer/Counter2 Overflow

13

0x018

TIMER1 CAPT

Timer/Counter1 Capture Event

14

0x01A

TIMER1 COMPA

Timer/Counter1 Compare Match A

15

0x01C

TIMER1 COMPB

Timer/Counter1 Compare Match B

16

0x01E

TIMER1 OVF

Timer/Counter1 Overflow

17

0x020

TIMER0 COMP

Timer/Counter0 Compare Match

18

0x022

TIMER0 OVF

Timer/Counter0 Overflow

19

0x024

SPI, STC

Serial Transfer Complete

20

0x026

USART0, RXC

USART0, Rx Complete

21

0x028

USART1, RXC

USART1, Rx Complete

22

0x02A

USART0, UDRE

USART0 Data Register Empty

23

0x02C

USART1, UDRE

USART1 Data Register Empty

24

0x02E

USART0, TXC

USART0, Tx Complete

25

0x030

USART1, TXC

USART1, Tx Complete

26

0x032

EE_RDY

EEPROM Ready

27

0x034

ANA_COMP

Analog Comparator

28

0x036

SPM_RDY

Store Program Memory Ready
