263
ATmega162/V
2513E–AVR–09/03
Electrical Characteristics
DC Characteristics
Absolute Maximum Ratings*
Operating Temperature .................................. -55
°
C to +125
°
C *NOTICE: Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect device
reliability.
Storage Temperature ..................................... -65°C to +150°C
Voltage on any Pin except RESET
with respect to Ground ................................-0.5V to V
CC
+0.5V
Voltage on RESET with respect to Ground......-0.5V to +13.0V
Maximum Operating Voltage ............................................ 6.0V
DC Current per I/O Pin ............................................... 40.0 mA
DC Current V
CC
and GND Pins................................ 200.0 mA
T
A
= -40
°
C to 85
°
C, V
CC
= 1.8V to 5.5V (unless otherwise noted)
Symbol Parameter Condition Min. Typ. Max. Units
V
IL
Input Low Voltage, Except XTAL1 pin
V
CC
= 1.8 - 2.4V
V
CC
= 2.4 - 5.5V
-0.5
-0.5 0.2 V
CC
(1)
0.3 V
CC
(1)
V
V
IL1
Input Low Voltage, XTAL1 pin V
CC
= 1.8 - 5.5V -0.5 0.1 V
CC
(1) V
V
IH
Input High Voltage, Except XTAL1
and RESET pin V
CC
= 1.8 - 2.4V
V
CC
= 2.4 - 5.5V
0.7 V
CC
(2)
0.6 V
CC
(2)
V
CC
+ 0.5
V
CC
+ 0.5
V
V
IH1
Input High Voltage, XTAL1 pin
V
CC
= 1.8 - 2.4V
V
CC
= 2.4 - 5.5V
0.8 V
CC
(2)
0.7 V
CC
(2)
V
CC
+ 0.5
V
CC
+ 0.5
V
V
IH2
Input High Voltage, RESET pin V
CC
= 1.8 - 5.5V 0.9 V
CC
(2) V
CC
+ 0.5 V
V
OL
Output Low Voltage (3) , Ports A, B, C,
D, and E
I
OL
= 20 mA, V
CC
= 5V
I
OL
= 10 mA, V
CC
= 3V
0.7
0.5 V
V
V
OH
Output High Voltage (4) , Ports A, B, C,
D, and E
I
OL
= -20 mA, V
CC
= 5V
I
OL
= -5 mA, V
CC
= 3V
4.2
2.3 V
V
I
IL
Input Leakage Current I/O Pin
Vcc = 5.5 V, pin low
(absolute value)
1 µA
I
IH
Input Leakage Current I/O Pin
Vcc = 5.5 V, pin high
(absolute value)
1 µA
R
RST
Reset Pull-up Resistor 30 60 k
Ω
R
pu
I/O Pin Pull-up Resistor 20 50 k
Ω
