303
ATmega162/V
2513E–AVR–09/03
Register Summary
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
(0xFF) Reserved – – – – – – – –
.. Reserved – – – – – – – –
(0x9E) Reserved – – – – – – – –
(0x9D) Reserved – – – – – – – –
(0x9C) Reserved – – – – – – – –
(0x9B) Reserved – – – – – – – –
(0x9A) Reserved – – – – – – – –
(0x99) Reserved – – – – – – – –
(0x98) Reserved – – – – – – – –
(0x97) Reserved – – – – – – – –
(0x96) Reserved – – – – – – – –
(0x95) Reserved – – – – – – – –
(0x94) Reserved – – – – – – – –
(0x93) Reserved – – – – – – – –
(0x92) Reserved – – – – – – – –
(0x91) Reserved – – – – – – – –
(0x90) Reserved – – – – – – – –
(0x8F) Reserved – – – – – – – –
(0x8E) Reserved – – – – – – – –
(0x8D) Reserved – – – – – – – –
(0x8C) Reserved – – – – – – – –
(0x8B) TCCR3A COM3A1 COM3A0 COM3B1 COM3B0 FOC3A FOC3B WGM31 WGM30 130
(0x8A) TCCR3B ICNC3 ICES3 – WGM33 WGM32 CS32 CS31 CS30 127
(0x89) TCNT3H Timer/Counter3 – Counter Register High Byte 132
(0x88) TCNT3L Timer/Counter3 – Counter Register Low Byte 132
(0x87) OCR3AH Timer/Counter3 – Output Compare Register A High Byte 132
(0x86) OCR3AL Timer/Counter3 – Output Compare Register A Low Byte 132
(0x85) OCR3BH Timer/Counter3 – Output Compare Register B High Byte 132
(0x84) OCR3BL Timer/Counter3 – Output Compare Register B Low Byte 132
(0x83) Reserved – – – – – – – –
(0x82) Reserved – – – – – – – –
(0x81) ICR3H Timer/Counter3 – Input Capture Register High Byte 133
(0x80) ICR3L Timer/Counter3 – Input Capture Register Low Byte 133
(0x7F) Reserved – – – – – – – –
(0x7E) Reserved – – – – – – – –
(0x7D) ETIMSK – – TICIE3 OCIE3A OCIE3B TOIE3 – – 134
(0x7C) ETIFR – – ICF3 OCF3A OCF3B TOV3 – – 135
(0x7B) Reserved – – – – – – – –
(0x7A) Reserved – – – – – – – –
(0x79) Reserved – – – – – – – –
(0x78) Reserved – – – – – – – –
(0x77) Reserved – – – – – – – –
(0x76) Reserved – – – – – – – –
(0x75) Reserved – – – – – – – –
(0x74) Reserved – – – – – – – –
(0x73) Reserved – – – – – – – –
(0x72) Reserved – – – – – – – –
(0x71) Reserved – – – – – – – –
(0x70) Reserved – – – – – – – –
(0x6F) Reserved – – – – – – – –
(0x6E) Reserved – – – – – – – –
(0x6D) Reserved – – – – – – – –
(0x6C) PCMSK1 PCINT15 PCINT14 PCINT13 PCINT12 PCINT11 PCINT10 PCINT9 PCINT8 87
(0x6B) PCMSK0 PCINT7 PCINT6 PCINT5 PCINT4 PCINT3 PCINT2 PCINT1 PCINT0 87
(0x6A) Reserved – – – – – – – –
(0x69) Reserved – – – – – – – –
(0x68) Reserved – – – – – – – –
(0x67) Reserved – – – – – – – –
(0x66) Reserved – – – – – – – –
(0x65) Reserved – – – – – – – –
(0x64) Reserved – – – – – – – –
(0x63) Reserved – – – – – – – –
(0x62) Reserved – – – – – – – –
(0x61) CLKPR CLKPCE – – – CLKPS3 CLKPS2 CLKPS1 CLKPS0 39
