ATmega603/103
33
• Bit 2 - TOV1: Timer/Counter1 Overflow Flag
The TOV1 is set (one) when an overflow occurs in Timer/Counter1. TOV1 is cleared by hardware when executing the cor-
responding interrupt handling vector. Alternatively, TOV1 is cleared by writing a logic one to the flag. When the I-bit in
SREG, and TOIE1 (Timer/Counter1 Overflow Interrupt Enable), and TOV1 are set (one), the Timer/Counter1 Overflow
Interrupt is executed. In PWM mode, this bit is set when Timer/Counter1 advances from $0000.
•
Bit 1 - OCF0: Output Compare Flag 0
The OCF0 bit is set (one) when compare match occurs between Timer/Counter0 and the data in OCR0 - Output Compare
Register 0. OCF0 is cleared by hardware when executing the corresponding interrupt handling vector. Alternatively, OCF0
is cleared by writing a logic one to the flag. When the I-bit in SREG, and OCIE0 (Timer/Counter2 Compare Interrupt
Enable), and the OCF0 are set (one), the Timer/Counter0 Output Compare Interrupt is executed.
•
Bit 0 - TOV0: Timer/Counter0 Overflow Flag
The bit TOV0 is set (one) when an overflow occurs in Timer/Counter0. TOV0 is cleared by hardware when executing the
corresponding interrupt handling vector. Alternatively, TOV0 is cleared by writing a logic one to the flag. When the SREG I-
bit, and TOIE0 (Timer/Counter0 Overflow Interrupt Enable), and TOV0 are set (one), the Timer/Counter0 Overflow interrupt
is executed. In PWM mode, this bit is set when Timer/Counter0 advances from $00.
Interrupt Response Time
The interrupt execution response for all the enabled AVR interrupts is 4 clock cycles minimum. 4 clock cycles after the
interrupt flag has been set, the program vector address for the actual interrupt handling routine is executed. During this 4
clock cycle period, the Program Counter (2 bytes) is pushed onto the Stack, and the Stack Pointer is decremented by 2.
The vector is normally a jump to the interrupt routine, and this jump takes 3 clock cycles. If an interrupt occurs during exe-
cution of a multi-cycle instruction, this instruction is completed before the interrupt is served.
A return from an interrupt handling routine (same as for a subroutine call routine) takes 4 clock cycles. During these 4 clock
cycles, the Program Counter (2 bytes) is popped back from the Stack, and the Stack Pointer is incremented by 2. When the
AVR exits from an interrupt, it will always return to the main program and execute one more instruction before any pending
interrupt is served.
Sleep Modes
To enter any of the three sleep modes, the SE bit in MCUCR must be set (one) and a SLEEP instruction must be executed.
The SM1 and SM0 bits in the MCUCR register select which sleep mode (Idle, Power Down, or Power Save) will be acti-
vated by the SLEEP instruction, see Table 4.
If an enabled interrupt occurs while the MCU is in a sleep mode, the MCU awakes, executes the interrupt routine, and
resumes execution from the instruction following SLEEP. The contents of the register file, SRAM, and I/O memory are unal-
tered. If a reset occurs during sleep mode, the MCU wakes up and executes from the Reset vector
Idle Mode
When the SM1/SM0 bits are set to 00, the SLEEP instruction makes the MCU enter the Idle Mode, stopping the CPU but
allowing SPI, UART, Analog Comparator, ADC, Timer/Counters, Watchdog and the interrupt system to continue operating.
This enables the MCU to wake up from external triggered interrupts as well as internal ones like the Timer Overflow and
UART Receive Complete interrupts. If wake-up from the Analog Comparator interrupt is not required, the analog compara-
tor can be powered down by setting the ACD-bit in the Analog Comparator Control and Status register - ACSR. This will
reduce power consumption in Idle Mode. When the MCU wakes up from Idle mode, the CPU starts program execution
immediately.
