1
Features
• Utilizes the AVR ® RISC Architecture
• AVR - High-performance and Low-power RISC Architecture
– 120/121 Powerful Instructions - Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers + Peripheral Control Registers
– Up to 6 MIPS Throughput at 6 MHz
• Data and Nonvolatile Program Memory
– 64K/128K Bytes of In-System Programmable Flash
Endurance: 1,000 Write/Erase Cycles
– 4K Bytes Internal SRAM
– 2K/4K Bytes of In-System Programmable EEPROM
Endurance: 100,000 Write/Erase Cycles
– Programming Lock for Flash Program and EEPROM Data Security
– SPI Interface for In-System Programming
• Peripheral Features
– On-chip Analog Comparator
– Programmable Watchdog Timer with On-chip Oscillator
– Programmable Serial UART
– Master/Slave SPI Serial Interface
– Real Time Counter (RTC) with Separate Oscillator
– Two 8-bit Timer/Counters with Separate Prescaler and PWM
– Expanded 16-bit Timer/Counter system, with Separate Prescaler,
Compare, Capture Modes and Dual 8-, 9-, or 10-bit PWM
– Programmable Watchdog Timer with On-chip Oscillator
– 8-channel, 10-bit ADC
• Special Microcontroller Features
– Low-power Idle, Power Save and Power Down Modes
– Software Selectable Clock Frequency
– External and Internal Interrupt Sources
• Specifications
– Low-power, High-speed CMOS Process Technology
– Fully Static Operation
• Power Consumption at 4 MHz, 3V, 25°C
– Active: 5.5 mA
– Idle Mode: 1.6 mA
– Power Down Mode: < 1 µA
• I/O and Packages
– 32 Programmable I/O Lines, 8 Output Lines, 8 Input Lines
– 64-pin TQFP
• Operating Voltages
– 2.7 - 3.6V (ATmega603L and ATmega103L)
– 4.0 - 5.5V (ATmega603 and ATmega103)
• Speed Grades
– 0 - 4 MHz (ATmega603L and ATmega103L)
– 0 - 6 MHz (ATmega603 and ATmega103)
Rev. 0945D–06/99
8-bit
Microcontroller
with 64K/128K
Bytes In-System
Programmable
Flash
ATmega603
ATmega603L
ATmega103
ATmega103L
Preliminary
