DS21455/DS21458 Quad T1/E1/J1 Transceivers

152 of 270

INFO5, INFO6

HDLC #1 Information Register
HDLC #2 Information Register

2Eh, 2Fh

Bit

# 7

6 5 4 3 2 1 0

Name — —

TEMPTY

TFULL

REMPTY

PS2 PS1 PS0

Default

0 0 0 0 0 0 0

Bits 0 to 2/Receive Packet Status (PS0 to PS2). These are real-time bits indicating the status as of the last read of the receive
FIFO.

PS2 PS1 PS0

PACKET

STATUS

0 0 0

In Progress: End of message has not yet been reached.

0 0 1

Packet OK: Packet ended with correct CRC codeword.

0 1 0

CRC Error: A closing flag was detected, preceded by a corrupt CRC codeword.

0 1 1

Abort: Packet ended because an abort signal was detected (seven or more ones in a row).

1 0 0

Overrun: HDLC controller terminated reception of packet because receive FIFO is full.

1 0 1

Message Too Short: Three or fewer bytes including CRC.

Bit 3/Receive FIFO Empty (REMPTY). A real-time bit that is set high when the receive FIFO is empty.

Bit 4/Transmit FIFO Full (TFULL). A real-time bit that is set high when the FIFO is full.

Bit 5/Transmit FIFO Empty (TEMPTY). A real-time bit that is set high when the FIFO is empty.

Register Name:

INFO4

HDLC Event Information Register #4

2Dh

Bit

# 7 6 5 4 3 2 1 0

Name

—

H2UDR H2OBT H1UDR H1OBT

Default

0 0 0 0 0 0 0 0

Bit 0/HDLC #1 Opening Byte Event (H1OBT). Set when the next byte available in the receive FIFO is the first byte of a
message.

Bit 1/HDLC #1 Transmit FIFO Underrun Event (H1UDR). Set when the transmit FIFO empties out without having seen
the TMEND bit set. An abort is automatically sent. This bit is latched and will be cleared when read.

Bit 2/HDLC #2 Opening Byte Event (H2OBT). Set when the next byte available in the receive FIFO is the first byte of a
message.

Bit 3/HDLC #2 Transmit FIFO Underrun Event (H2UDR). Set when the transmit FIFO empties out without having seen
the TMEND bit set. An abort is automatically sent. This bit is latched and will be cleared when read.
