IPDirector V.5.8 – User Manual – Part 7: Editing - IPEdit
EVS Broadcast Equipment – July 2010
Issue 5.8.B
29
• 2 tracks of 4 mono channels
• 4 tracks of 2 mono channels
• 1 track of 2 mono channels, 1 track of 6 mono channels
• 1 track of 6 mono channels, 1 track of 2 mono channels
3.8.4 E
XAMPLE
The editor wants to add the clip loaded on the Player to the timeline using the
Insert button in the Player.
The clip contains 4 audio tracks of 2 mono channels. All the tracks are selected in
the timeline. The editor performs the following selection in the check boxes of the
Player Track Selection:
In this case, the following will happen:
• The tracks selected on the Player will be added on the same position as in the
source clip: G1 onto G1 and a2 onto a2, a3 onto a3, etc.
• The channel a1 of the track G1 not selected in the Player will be muted in the
timeline.
• As the channels of the track G3 and G4 remain unselected, a blank element
will be added to the timeline, instead of the track itself.
The following screenshot shows how the clip is inserted into the timeline:
