Garmin G1000 Pilot’s Guide for the Mooney M20M/M20R/M20TN 190-00647-00 Rev. A 8-2
ADDITIONAL FEATURES
XM INFORMATION PAGE
NOTE: The DONE Softkey on the XM Information Page (Auxiliary Page Group) is used to save GDL 69A
activation data when the XM services are initially set up. It is not used during normal XM Radio operation,
but there should be no adverse effects if inadvertently selected during flight. Refer to the GDL 69/69A XM
Satellite Radio Activation Instructions (190-00355-04, Rev F or later) for further information.
The XM Information Page provides XM Radio identification numbers, service level, and weather products.
Selecting the XM Information Page:
1) Turn the large FMS Knob to select the Auxiliary Page Group.
2) Turn the small FMS Knob to select the AUX - XM Information Page (fifth page of six in the AUX Group). RADIO
and INFO Softkeys are displayed.
3) Press the INFO Softkey to show Radio IDs, Service Class, and Weather Products.
Figure 8-1 XM Information Page
Audio
Radio ID
Weather
Products
Window
Data
Radio ID
DONE Softkey
is Used to Save
Activation Data
During Initial Setup.
RADIO
and INFO
Softkeys
Each Data Link Receiver contains a unique Data Radio ID and Audio Radio IDs that allow XM to communicate
with the radio. The owner must activate XM service by providing the appropriate Radio ID(s) to XM to authorize
the installed services for that radio. If XM services have not been activated, all the weather product boxes are
cleared on the XM Information Page and a yellow ‘Activation Required’ message shows up in the center of the
Weather Data Link Page (Map Page Group).
The ‘Service Class’ refers to the groupings of weather products available for subscription.
The Weather Products Window shows the list of available weather products and indicates the selected
products for the current subscription. The boxes for active weather products are filled. Before activation, all
boxes are cleared.
