Garmin G1000 Pilot’s Guide for the Mooney M20M/M20R/M20TN 190-00647-00 Rev. A 1-16
SYSTEM OVERVIEW
BRG2 Cycles the Bearing 2 Information Window through:
NAV2: Waypoint frequency/identifier and DME information
GPS: Waypoint identifier and GPS distance information
ADF: Waypoint frequency
Off: Removes window
STD BARO Sets barometric pressure to 29.92 in Hg (1013 hPa if METRIC Softkey is selected)
• OBS Selects OBS Mode on the CDI when navigating by GPS (only available with active leg)
• CDI Cycles CDI through GPS, NAV1 (VOR/LOC), and NAV2 (VOR/LOC) navigation sources
• ADF/DME Displays/removes ADF/DME Radio Tuning Window (optional; may appear as ADF, DME, or
ADF/DME depending on installation)
BACK
Press the OFF or BACK Softkey to
return to the top-level softkeys.
DCLTR
DCLTR-2
DCLTR-3
DCLTR-1
TOPO ALERTS NEXRAD
(optional)
TERRAIN XM LTNG
(optional)
OFF TRAFFIC
INSET
INSET XPDR IDENT TMR/REF NRST ALERTS OBS PFD CDI ADF/DME
(optional)
Press the CDI Softkey to cycle through
navigation sources:
- GPS
- NAV1 (VOR/LOC)
- NAV2 (VOR/LOC)
ARC HSI STD BARO BACK ALERTS METRIC DFLTS 360 HSI
PFD
BRG1 BRG2 DME
(optional)
Press the BRG1/BRG2 softkeys to display/
remove the Bearing Information windows
and cycle through bearing sources:
- NAV1/NAV2
- GPS
- ADF
Press the STD BARO or BACK Softkey
to return to the top-level softkeys.
Press the BACK Softkey to return
to the top-level softkeys.
Press the IDENT or BACK Softkey
to return to the top-level softkeys.
XPDR
STBY ON ALT VFR IDENT BACK ALERTS CODE
IDENT BACK ALERTS 0 1 2 3 4 5 6 7 BKSP
Figure 1-15 PFD Configuration Softkeys
• XPDR Displays transponder mode selection softkeys:
STBY Selects standby mode (Transponder does not reply to any interrogations)
ON Selects Mode A (Transponder replies to interrogations)
ALT Selects Mode C – altitude reporting mode (Transponder replies to identification and altitude
interrogations)
VFR Automatically enters the VFR code (1200 in U.S.A. only)
CODE Displays transponder code selection softkeys 0-7
0 — 7 Use numbers to enter code
BKSP Removes numbers entered, one at a time
• IDENT Activates the Special Position Identification (SPI) pulse for 18 seconds, identifying the
transponder return on the ATC screen
• TMR/REF Displays/removes Timer/References Window
• NRST Displays/removes Nearest Airports Window
• ALERTS Displays/removes Alerts Window
