190-00647-00 Rev. A Garmin G1000 Pilot’s Guide for the Mooney M20M/M20R/M20TN 7-1
AUTOMATIC FLIGHT CONTROL SYSTEM
SECTION 7 AUTOMATIC FLIGHT CONTROL SYSTEM
7.1 AFCS OVERVIEW
NOTE: The Aircraft Flight Manual (AFM) always supersedes the information in this guide.
NOTE: A failure of the primary (#1) GIA 63 Integrated Avionics Unit (IAU) results in loss of the AFCS. Any IAU
failure results in loss of the autopilot and manual electric trim.
The GFC 700 is a digital Automatic Flight Control System (AFCS), fully integrated within the G1000 System
avionics architecture. Refer to Figure 1-1 in the System Overview for a block diagram supporting this system
description. GFC 700 AFCS functionality in Mooney M20M/M20R/M20TN aircraft is distributed across the
following Line Replaceable Units (LRUs):
• GDU 1040 Primary Flight Display (PFD)
• GDU 1042 Multi-Function Display (MFD)
• GIA 63 Integrated Avionics Units (2)
• GSA 81 AFCS Servos (3)
• GSM 85 Servo Mounts (3)
The GFC 700 AFCS performs these main operating functions:
• Flight Director (FD) — Flight director operation takes place within the primary (#1) GIA 63 Integrated
Avionics Unit (IAU). Flight director commands are displayed on the PFD. The flight director provides:
– Command Bars showing pitch/roll guidance
– Pitch/roll mode selection and processing
– Autopilot communication
• Autopilot (AP) — Autopilot operation occurs within the pitch, roll, and pitch trim servos and provides servo
monitoring and automatic flight control in response to flight director steering commands, AHRS attitude and
rate information, and airspeed.
• Manual Electric Trim (MET) — The pitch trim servo provides manual electric trim capability when the
autopilot is not engaged.
