190-00647-00 Rev. A Garmin G1000 Pilot’s Guide for the Mooney M20M/M20R/M20TN 7-13
AUTOMATIC FLIGHT CONTROL SYSTEM
GO AROUND (GA) MODE
Pushing the Go Around Switch engages the flight director in a wings level, 7° pitch-up attitude, allowing the
execution of a missed approach or a go around. This mode is a couple pitch and roll mode and is annunciated
as ‘GA’ in both the pitch and roll active mode fields. Go Around Mode disengages the autopilot and arms
Altitude Hold Mode automatically. Subsequent autopilot engagement is allowed. Attempts to modify the
aircraft attitude (i.e., with the CWS Button or NOSE UP/NOSE DN keys) result in reversion to Pitch and Roll
Hold modes.
Flight Director
Command Bars
Indicate Climb
Go Around Mode Active
Autopilot Disconnect
Annunciation Flashes
Yellow 5 sec
Figure 7-11 Go Around Mode
