1.7 ACCESSING G1000 FUNCTIONALITY
MENUS
The G1000 has a MENU Key that, when pressed, displays a context-sensitive list of options. This options list
allows the user to access additional features or make settings changes which specifically relate to the currently
displayed window/page. There is no all-encompassing menu. Some menus provide access to additional
submenus that are used to view, edit, select, and review options. Menus display ‘NO OPTIONS’ when there are
no options for the window/page selected. The main controls used in association with all window/page group
operations are described in section 1.3. Softkey selection does not display menus or submenus.
Navigating the Page Menu Window
1) Press the MENU Key to display the Page Menu Window.
2) Turn the FMS Knob to scroll through a list of available options (a scroll bar appears to the right of the window
when the option list is longer than the window).
3) Press the ENT Key to select the desired option.
4) The CLR Key may be pressed to remove the menu and cancel the operation. Pressing the FMS Knob also
removes the displayed menu.
Figure 1-23 Page Menu Examples
No Options with
NRST Window
Displayed on the
PFD
Options
with FPL
Window
Displayed
MFD PAGE GROUPS
NOTE: Refer to the Flight Management, Hazard Avoidance, and Additional Features sections for details on
specific pages.
The page group and active page title box are displayed in the upper right of the screen.
Page Group Active Page Title
Figure 1-24 Page Title Box
