Garmin G1000 Piper PA-46 Matrix - Manual (Page 308)

Garmin G1000 Pilot’s Guide for the Piper PA-46 Mirage/Matrix 190-01108-00 Rev. B 294
FLIGHT MANAGEMENT
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EICAS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL FEA
TURES
APPENDICES
INDEX
Figure 5-146 Dead Reckoning Mode - GPS Derived Data Shown in Yellow
Distance &
Bearing
GPS Navigation
Lost Message
Dead Reckoning
Annunciation
Subdued Aircraft
Symbol
Nav. Data Bar
All data except
Active Leg, TAS,
and DTK are in
yellow
Dead Reckoning
Annunciaion
Wind Data
Bearing
Pointer/
Distance
Current
Track
Indicator
Course Deviation
Indicator
NOTE: The Inset Map is removed from the PFD any time aircraft pitch is greater than +30° or less than –20°,
or when a 65° bank angle is reached.
