Xerox Document Centre System Administration Guide
Set up scanning (TCP/IP)
1.
Open your Web browser and enter the TCP/IP address of the
Document Centre in the Address or Location field.
2.
Click the Properties tab or click Properties in the directory
tree.
3.
Select Services, then select Distribution Templates in the
directory tree.
4.
Select Repository Setup in the directory tree.
5.
Select a repository from the Repository List drop-down list.
6.
Select TCP/IP for Protocols.
7.
Type the IP Address of the File Server.
8.
Type the Directory path where the files will be stored.
9.
Type the Login Name and Password for the repository.
Retype the password to verify it in Retype Password.
10. Click Apply New Settings to accept the changes or Restore
Settings to return the settings to their previous values.
