Raw TCP/IP Printing
NOTE TCP/IP must be enabled.
Raw TCP/IP is a printing protocol that is similar to LPR printing.
Also known as a direct TCP/IP connection or sockets interface, it
sends information directly to the Document Centre and does not
require a Line Printer Daemon (LPD). The advantages are that
connections stay open for multiple print files and spooling is not
needed, therefore, printing is faster and more reliable than LPD
printing.
Raw TCP/IP printing is contained in Windows 2000 and other
third-party applications and operating systems.
To specify Raw TCP/IP printing settings:
1. Open your Web browser and enter the TCP/IP address of the
Document Centre in the Address or Location field.
2. Click the Properties tab or click Properties in the directory
tree.
3. Select Connectivity, then select Protocols in the directory
tree.
