Page 16 - 48
Xerox Document Centre System Administration Guide
Token Ring
NOTE
If the token ring network interface is not installed, this page is
unavailable.
To specify token ring settings:
1.
Open your Web browser and enter the TCP/IP address of the
Document Centre in the Address or Location field.
2.
Click the Properties tab or click Properties in the directory
tree.
3.
Select Connectivity, then select Physical Connections in the
directory tree.
4.
Select Token Ring in the directory tree.
5.
Select the desired Rated Speed from the drop-down list, either
4 or 16 Mbps.
6.
Type the machine address in M.A.C. Address.
7.
Select None, All Broadcasts, or Single Routes Broadcasts from
the Source Routing drop-down list.
8.
Click Save New Settings to accept the changes or Restore
Settings to return the settings to their previous values.
NOTE
If the token ring network interface is not installed, this page is
unavailable.
