Xerox Document Centre System Administration Guide Page 16 - 61
1
6
. Int
ern
et
Se
rv
ic
es
16
. Int
e
rne
t Se
rv
ic
e
s
7. Enter a UDP Port Number of the SNMP manager that will
receive traps. The default is 162 (decimal).
8. Select the SNMP version that matches the version of the
SNMP manager. The default is SNMP v1.
9. Enter the Trap Community Name.
10. Select the Traps to be Received:
•
Printer Traps
• Job Monitoring Traps
• Cold Start Generic Traps
• Warm Start Generic Traps
• Authentication Failure Generic Traps
NOTE Authentication Failure Generic Traps must be enabled on the
SNMP Properties Configuration Page before you can select it.
11. Click Apply New Settings to accept the changes or Restore
Settings to return the settings to their previous values.
To Add IPX Addresses to the Trap Destination
Addresses List:
1. Open your Web browser and enter the TCP/IP address of the
Document Centre in the Address or Location field.
2. Click the Properties tab or click Properties in the directory
tree.
3. Select Connectivity, then select Protocols in the directory
tree.
