Xerox 480 ST - Manual (Page 171)

Xerox Document Centre System Administration Guide Page 16 - 65
1
6
. Int
ern
et
Se
rv
ic
es
16
. Int
e
rne
t Se
rv
ic
e
s
8. Type the maximum number of connections allowed in Maxi-
mum Connections.
9. Select the workgroup from the Workgroup drop-down list.
10. Type the SMB Host Name and optionally type a descriptive
comment in SMB Host Name Comment.
11. Type the Share Name and optionally type a descriptive com-
ment in Share Name Comment.
12. Click Apply New Settings to accept the changes or Restore
Settings to return the settings to their previous values.
NOTE The settings are not applied until you restart the Document Centre.
Line Printer Daemon (LPR/LPD)
To specify LPR/LPD settings:
1. Open your Web browser and enter the TCP/IP address of the
Document Centre in the Address or Location field.
2. Click the Properties tab or click Properties in the directory
tree.
3. Select Connectivity, then select Protocols in the directory
tree.
