ZyWALL 100 Internet Security Gateway
9-8 Remote Node Setup
9.3 Editing TCP/IP Options (with Ethernet Encapsulation)
Move the cursor to the Edit IP field in menu 11.1, then press [SPACE BAR] to select Yes. Press
[ENTER]
to open Menu 11.3 - Network Layer Options.
Figure 9-5 Menu 11.3 — Remote Node Network Layer Options for Ethernet Encapsulation
The next table gives you instructions about configuring remote node network layer options.
Table 9-4 Remote Node Network Layer Options Menu Fields
FIELD DESCRIPTION EXAMPLE
IP Address
Assignment If your ISP did not assign you an explicit IP address, press [SPACE
BAR] and then [ENTER] to select Dynamic; otherwise select Static
and enter the IP address & subnet mask in the following fields. Dynamic
(default)
IP Address If you have a Static IP Assignment, enter the IP address assigned to
you by your ISP.
IP Subnet
Mask If you have a Static IP Assignment, enter the subnet mask assigned to
you.
Gateway IP
Addr If you have a Static IP Assignment, enter the gateway IP address
assigned to you.
Network
Address
Translation Press [SPACE BAR] and then [ENTER] to select either Full Feature,
None or SUA Only. See the NAT chapter for a full discussion on this
feature. SUA Only
(default)
Menu 11.3 - Remote Node Network Layer Options
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Addr= N/A
Network Address Translation= SUA Only
Metric= N/A
Private= N/A
RIP Direction= None
Version= N/A
Multicast= None
Enter here to CONFIRM or ESC to CANCEL:
