ZyWALL 100 Internet Security Gateway
IPSec Log 30-1
Chapter 30
IPSec Log
This chapter interprets common IPSec log messages.
30.1 VPN Initiator IPSec Log
To view the IPSec and IKE connection log, type 3 in menu 27 and press [ENTER] to display the IPSec log as
shown next. The following figure shows a typical log from the initiator of a VPN connection.
Figure 30-1 Example VPN Initiator IPSec Log
Index: Date/Time: Log:
------------------------------------------------------------
001 01 Jan 08:02:22 Send Main Mode request to <192.168.100.101>
002 01 Jan 08:02:22 Send:
003 01 Jan 08:02:22 Recv:
004 01 Jan 08:02:24 Send:
005 01 Jan 08:02:24 Recv:
006 01 Jan 08:02:26 Send:
007 01 Jan 08:02:26 Recv:
008 01 Jan 08:02:26 Phase 1 IKE SA process done
009 01 Jan 08:02:26 Start Phase 2: Quick Mode
010 01 Jan 08:02:26 Send:
011 01 Jan 08:02:26 Recv:
012 01 Jan 08:02:26 Send:
Clear IPSec Log (y/n):
