ZyWALL 100 Internet Security Gateway
Remote Node Setup 9-7
Figure 9-4 Menu 11.1 — Remote Node Profile for PPTP Encapsulation
The next table shows how to configure fields in menu 11.1 not previously discussed above.
Table 9-3 Fields in Menu 11.1 (PPTP Encapsulation)
FIELD DESCRIPTION EXAMPLE
Encapsulation Press [SPACE BAR] and then [ENTER] to select PPTP. You must
also go to menu 11.3 to check the IP Address setting once you
have selected the encapsulation method. PPTP
My IP Addr Enter the IP address of the WAN Ethernet port. 10.0.0.140
My Server IP Addr Enter the IP address of the ANT modem. 10.0.0.138
Connection
ID/Name
Enter the connection ID or connection name in the ANT. It must
follow the “c:id” and “n:name” format.
This field is optional and depends on the requirements of your
xDSL Modem.
N:My ISP
Schedules You can apply up to four schedule sets here. For more details refer
to the Call Schedule Setup chapter.
Nailed-Up
Connections Press [SPACE BAR] and then [ENTER] to select Yes if you want to
make the connection to this remote node a nailed-up connection. No
Menu 11.1 - Remote Node Profile
Rem Node Name= ChangeMe Route= IP
Active= Yes
Encapsulation= PPTP Edit IP= No
Service Type= Standard Telco Option:
Service Name=N/A Allocated Budget(min)= 0
Outgoing= Period(hr)= 0
My Login=
Schedules=
My Password= ******** Nailed-up Connections=
Authen= CHAP/PAP
Session Options:
PPTP : Edit Filter Sets= No
My IP Addr= Idle Timeout(sec)= 100
Server IP Addr=
Connection ID/Name=
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
