ZyWALL 100 Internet Security Gateway
NAT 12-9
15.1. You can only configure Set 1. Set 255 is used for SUA. When you select Full Feature in menu 4
or 11.3, the SMT will use Set 1, which supports all mapping types as outlined in Table 12-2. When you
select SUA Only, the SMT will use the pre-configured Set 255 (read only).
The server set is a list of LAN and DMZ servers mapped to external ports. To use this set, a server rule
must be set up inside the NAT address mapping set. Please see section 12.4 for further information on these
menus. To configure NAT, enter 15 from the main menu to bring up the following screen.
Figure 12-5 Menu 15 — NAT Setup
Configure DMZ and LAN IP addresses in NAT menus 15.1 and 15.2 . DMZ IP
addresses must be on subnets separate from LAN IP addresses.
12.3.1 Address Mapping Sets
Enter 1 to bring up Menu 15.1 — Address Mapping Sets.
Figure 12-6 Menu 15.1 — Address Mapping Sets
SUA Address Mapping Set
Enter 255 to display the next screen (see also section 12.2.1). The fields in this menu cannot be changed.
Menu 15 — NAT Setup
1. Address Mapping Sets
2. Server Set
3. Trigger Port Setup
Enter Menu Selection Number:
Menu 15.1 — Address Mapping Sets
1.
255. SUA (read only)
Enter Menu Selection Number:
