ZyWALL 100 Internet Security Gateway
28-6 VPN/IPSec Setup
Figure 28-6 Menu 27.1 — IPSec Summary
Table 28-3 Menu 27.1 — IPSec Summary
FIELD DESCRIPTION EXAMPLE
# This is the VPN policy index number. 1
Name This field displays the unique identification name for this VPN rule. The
name may be up to 32 characters long but only 10 characters will be
displayed here. Taiwan
A Y signifies that this VPN rule is active. Y
Local Addr
Start When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
Single, this is a static IP address on the LAN behind your ZyWALL.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
Range, this is the beginning (static) IP address, in a range of computers
on the LAN behind your ZyWALL.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
SUBNET, this is a static IP address on the LAN behind your ZyWALL.
192.168.1.35
Menu 27.1 – IPSec Summary
# Name
A Local Addr Start - Local Addr End Encap IPSec Algorithm
Key Mgt Remote Addr Start - Remote Addr End Secure GW Addr
- ------ - ----------------- --------------- ------ ------------------
1 Taiwan Y 192.168.1.35 192.168.1.38 Tunnel ESP DES MD5
IKE 172.16.2.40 172.16.2.46 193.81.13.2
2 zw50 N 1.1.1.1 1.1.1.1 Tunnel AH SHA1
IKE 4.4.4.4 255.255.0.0 zw50test.zyxel.
3 China N 192.168.1.40 192.168.1.42 Tunnel ESP DES MD5
IKE N/A N/A 0.0.0.0
4
5
Select Command= None
Select Rule= N/A
Press ENTER to Confirm or ESC to Cancel:
