ZyWALL 100 Internet Security Gateway
16-16 Creating Custom Rules
16.8 Example Firewall Rule
The following Internet firewall rule example allows a syslog connection from the Internet.
Step 1. Click the Firewall link and then the Summary tab.
Step 2. Click the option button for a rule and then Edit to display the firewall rule configuration screen.
Figure 16-7 Firewall Rule Configuration Screen
Step 3. Click Any in the Source Address box and then click ScrDelete.
Step 4. Click ScrAdd under the Source Address box.
Step 5. Configure the Firewall IP Config screen as follows and click Apply.
Select WAN to LAN from the
drop-down list box.
