ZyWALL 100 Internet Security Gateway
5-4 WAN Setup
5.4.3 Response Strings
The response strings tell the ZyWALL the tags, or labels, immediately preceding the various call parameters
sent from the WAN device. The response strings have not been standardized; please consult the
documentation of your WAN device to find the correct tags.
To edit the advanced setup for the Dial Backup port, move the cursor to the Edit Advanced Setup field in
Menu 2 - WAN Setup, press the [SPACE BAR] to select Yes and then press [ENTER].
Figure 5-2 Menu 2.1 Advanced WAN Setup
The following table describes fields in this menu.
Table 5-2 Advanced WAN Port Setup — AT Commands Fields
FIELD DESCRIPTION DEFAULT
AT Command
Strings:
Dial Enter the AT Command string to make a call. atdt
Drop Enter the AT Command string to drop a call. “~” represents a one
second wait, e.g., “~~~+++~~ath” can be used if your modem has a
slow response time.
+++ath
Answer Enter the AT Command string to answer a call. ata
Drop DTR When
Hang Up Press the [SPACE BAR] to choose either Yes or No. When Yes
is selected (the default), the DTR (Data Terminal Ready) signal is
dropped after the “AT Command String: Drop” is sent out. Yes
Menu 2.1 - Advanced WAN Setup
AT Command Strings: Call Control:
Dial= atdt Dial Timeout(sec)= 60
Drop= ~~+++~~ath Retry Count= 0
Answer= ata Retry Interval(sec)= N/A
Drop Timeout(sec)= 20
Drop DTR When Hang Up= Yes Call Back Delay(sec)= 15
AT Response Strings:
CLID= NMBR =
Called Id=
Speed= CONNECT
