ZyWALL 100 Internet Security Gateway
2-2 Hardware Installation
LED COLOR STATUS MEANING
Green Off The 10M LAN is not connected.
On The ZyWALL is connected to a 10M LAN.
LAN 10M
Flashing The 10M LAN is sending or receiving packets.
Off The 100M LAN is not connected.
On The ZyWALL is connected to a 100Mbps LAN.
LAN
100M Orange
Flashing The 100M LAN is sending or receiving packets.
Green Off The 10M DMZ is not connected.
On The ZyWALL is connected to a 10M DMZ.
DMZ
10M
Flashing The 10M DMZ is sending/receiving packets.
Orange Off The 100M DMZ is not connected.
On The ZyWALL is connected to a 100Mbps DMZ.
DMZ
100M
Flashing The 100M DMZ is sending or receiving packets.
Off The 10M WAN link is not ready, or has failed.
On The 10M WAN link is OK.
WAN
10M Green
Flashing The 10M WAN link is sending or receiving packets.
Off The 100M WAN link is not ready, or has failed.
On The 100M WAN link is OK.
WAN
100M Orange
Flashing The 100M WAN link is sending or receiving
packets.
Off The backup port is not connected. AUX
LNK Green
On The backup port is connected.
Off The auxiliary port is not sending or receiving
packets. AUX
ACT Green
Flashing The auxiliary port is sending or receiving packets.
2.2 ZyWALL 100 Rear Panel and Connections
The following figure shows the rear panel of your ZyWALL 100.
