ZyWALL 100 Internet Security Gateway
IP Policy Routing 25-3
Menu 25.1 shows the summary of a policy set, including the criteria and the action of a single policy, and
whether a policy is active or not. Each policy contains two lines. The former part is the criteria of the
incoming packet and the latter is the action. Between these two parts, separator “|” means the action is taken
on criteria matched and separator “=” means the action is taken on criteria not matched.
Figure 25-4 Menu 25.1 — Sample IP Routing Policy Setup
Table 25-1 IP Routing Policy Setup
ABBREVIATION MEANING
Criterion SA Source IP Address
SP Source Port
DA Destination IP Address
DP Destination Port
P IP layer 4 protocol number (TCP=6, UDP=17…)
T Type of service of incoming packet
PR Precedence of incoming packet
Action GW Gateway IP address
T Outgoing Type of service
Menu 25.1 - IP Routing Policy Setup
# A Criteria/Action
- - --------------------------------------------------------------------------
1 Y SA=1.1.1.1-1.1.1.1,DA=2.2.2.2-2.2.2.5
SP=20-25,DP=20-25,P=6,T=NM,PR=0 |GW=192.168.1.1,T=MT,PR=0
2 N __________________________________________________________________________
__________________________________________________________________________
3 N __________________________________________________________________________
__________________________________________________________________________
4 N __________________________________________________________________________
__________________________________________________________________________
5 N __________________________________________________________________________
__________________________________________________________________________
6 N __________________________________________________________________________
__________________________________________________________________________
Enter Policy Rule Number (1-6) to Configure:
