ZyXEL Communications Internet Security Gateway ZyWALL 100 User Manual
Page 329
ZyWALL 100 Internet Security Gateway
Hardware Specifications
M
Diagram 9 WAN/LAN Cable Pin Layout
WAN/LAN Cable Pin Layout:
Straight-Through
Crossover
(Switch)
1 IRD +
(Adapter)
1 OTD +
(Switch)
1 IRD +
(Switch)
1 IRD +
2 IRD -
2 OTD -
2 IRD -
2 IRD -
3 OTD +
3 IRD +
3 OTD +
3 OTD +
6 OTD -
6 IRD -
6 OTD -
6 OTD -
Pin1
Pin 6
Pin 9
