ZyWALL 100 Internet Security Gateway
L Hardware Specifications
Appendix E
Hardware Specifications
Power Specification 100-240 VAC, 50/60Hz
Power Consumption 16 Watts maximum
Power Current 1.9 Amps
Fuse Rating 0.5 Amps, 250 VAC
MTBF 100000 hrs (Mean Time Between Failures)
Operation Temperature 0º C ~ 40º C
Ethernet Specification for
WAN 10/100Mbps Half / Full Auto-negotiation
Ethernet Specification for
DMZ 10/100Mbps Half / Full Auto-negotiation
Ethernet Specification for
LAN 10/100Mbps Half / Full Auto-negotiation
CONSOLE Port RS – 232
(F)
DB-9F Pin 1 = NON ; Pin 2 = DCE-RXD; Pin 3 = DCE -TXD; Pin 4 =
DCE -DTR; Pin 5 = GND; Pin 6 = DCE -DSR; Pin 7 = DCE -
RTS; Pin 8 = DCE -CTS; PIN 9 = NON. See following figure.
DIAL BACKUP RS – 232
(M) DB-9M Pin 1 = NON ; Pin 2 = DTE-RXD; Pin 3 = DTE-TXD; Pin 4 =
DTE-DTR; Pin 5 = GND; Pin 6 = DTE-DSR; Pin 7 = DTE-RTS;
Pin 8 = DTE-CTS; PIN 9 = NON. See following figure.
