ZyWALL 100 Internet Security Gateway
10-6 Backup Remote Node Setup
FIELD DESCRIPTION EXAMPLE
Network
Address
Translation Press [SPACE BAR] and then [ENTER] to select either Full Feature,
None or SUA Only. See the Network Address Translation (NAT) chapter
for a full discussion on this feature. None
(default)
Metric Enter a number from 1 to 15 to set this route’s priority among the three
routes the ZyWALL uses (see also Remote Node Setup and Traffic
Redirect) The smaller the number, the higher priority the route has. 15
(default)
Private This parameter determines if the ZyWALL will include the route to this
remote node in its RIP broadcasts. If set to Yes, this route is kept private
and not included in RIP broadcasts. If No, the route to this remote node
will be propagated to other hosts through RIP broadcasts. No
(default)
RIP
Direction Press [SPACE BAR] and then [ENTER] to select the RIP direction from
Both/ None/In Only/Out Only and None. Both
(default)
Version Press [SPACE BAR] and then [ENTER] to select the RIP version from
RIP-1/RIP-2B/RIP-2M.
RIP-1
Multicast IGMP (Internet Group Multicast Protocol) is a session-layer protocol
used to establish membership in a Multicast group. The ZyWALL
supports both IGMP version 1 (IGMP-v1) and version 2 (IGMP-v2).
Press the [SPACE BAR] to enable IP Multicasting or select None to
disable it. See the LAN Setup chapter for more information on this
feature. None
(default)
Once you have completed filling in Menu 11.3 Remote Node Network Layer Options, press [ENTER]
at the message “Press ENTER to Confirm...” to save your configuration and return to menu 11, or press
[ESC] at any time to cancel.
10.4 Editing Login Script
For some remote gateways, text login is required before PPP negotiation is started. The ZyWALL provides
a script facility for this purpose. The script has six programmable sets; each set is composed of an ‘Expect’
string and a ‘Send’ string. After matching a message from the server to the ‘Expect’ field, the ZyWALL
returns the set’s ‘Send’ string to the server.
For instance, a typical login sequence starts with the server printing a banner, a login prompt for you to
enter the user name and a password prompt to enter the password:
Welcome to Acme, Inc.
Login: myLogin
Password:
