ZyWALL 100 Internet Security Gateway
28-2 VPN/IPSec Setup
Figure 28-2 Menu 27 — VPN/IPSec Setup
28.2 IPSec Algorithms
The ESP and AH protocols are necessary to create a Security Association (SA), the foundation of an IPSec
VPN. An SA is built from the authentication provided by the AH and ESP protocols. The primary function
of key management is to establish and maintain the SA between systems. Once the SA is established, the
transport of data may commence.
28.2.1 AH (Authentication Header) Protocol
AH protocol (RFC 2402) was designed for integrity, authentication, sequence integrity (replay resistance),
and non-repudiation but not for confidentiality, for which the ESP was designed.
In applications where confidentiality is not required or not sanctioned by government encryption restrictions,
an AH can be employed to ensure integrity. This type of implementation does not protect the information
from dissemination but will allow for verification of the integrity of the information and authentication of the
originator.
28.2.2 ESP (Encapsulating Security Payload) Protocol
The ESP protocol (RFC 2406) provides encryption as well as some of the services offered by AH. ESP
authenticating properties are limited compared to the AH due to the non-inclusion of the IP header
information during the authentication process. However, ESP is sufficient if only the upper layer protocols
need to be authenticated.
An added feature of the ESP is payload padding, which further protects communications by concealing the
size of the packet being transmitted.
Menu 27 - VPN/IPSec Setup
1. IPSec Summary
2. SA Monitor
3. View IPSec Log
Enter Menu Selection Number:
