Reference [Mixer]
ZOOM MRS-1266
80
5.
Use the cursor up/down keys to select the EQ
parameter that you want to adjust, and turn the dial
to edit the value.
The parameters that can be selected and their ranges are as
follows.
● [EQ HIGH]
• EQ HI G
Adjusts the amount of high-range boost/cut.
Range: -12 - 0 - 12 (dB)
Default: 0
• EQ HI F
Adjusts the turnover frequency for high-range boost/cut.
Range: 500 - 18000 (Hz)
Default: 8000
● [EQ LOW]
• EQ LO G
Adjusts the amount of low-range boost/cut.
Range: -12 - 0 - 12 (dB)
Default: 0
• EQ LO F
Adjusts the turnover frequency for low-range boost/cut.
Range: 40 - 1600 (Hz)
Default: 125
H INT
If you press the [EQ HIGH] key while the EQ HIGH screen is
displayed, the key goes out and EQ HIGH is turned off.
Pressing the key once more activates it again. In the same
way, you can switch EQ LOW off and on by pressing the [EQ
LOW] key when the EQ LOW screen is displayed.
6.
Repeat steps 4 - 5 to adjust settings in the same
way for another range or EQ parameter.
7.
When you have finished adjusting settings, press
the [EXIT] key.
The unit returns to the main screen.
Adjusting depth of send/return effect
This section explains how to adjust the effect depth by
setting the volume that is sent from each channel to the send/
return effects (chorus/delay, reverb). Raising the send level
will produce a deeper effect.
1.
Press the [CHORUS/DELAY] key or [REVERB] key
to select a patch for the send/return effect.
The display changes and shows the currently selected patch
of the selected effect (chorus/delay or reverb).
2.
Turn the dial to select the patch you want to use.
When you have selected the patch, press the [EXIT] key.
3.
Press the [CHORUS/DELAY SEND] key or the
[REVERB SEND] key in the track parameter section
to select send/return effect.
Press the [CHORUS/DELAY SEND] key if you want to
adjust the chorus/delay send level or the [REVERB SEND]
key if you want to adjust the reverb send level.
4.
Press the status key for the desired track or drum/
bass sound.
5.
Turn the dial to select the effect depth.
Higher values result in more effect depth (stronger effect).
The range and default values for the parameters are shown
below.
● CHORUS/DELAY SEND: 0 - 100 (default: 0)
● REVERB SEND: 0 - 100 (default: 0)
0
TR4 TR4
CHO SEND
CHO SEND
