Reference [Mixer]
ZOOM MRS-1266
79
3.
Turn the dial to edit the value of the PAN parameter.
The PAN parameter can be adjusted in a range of L100 (far
left) - 0 (center) - R100 (far right).
4.
When you have finished adjusting the panning
value, press the [EXIT] key.
The unit returns to the main screen. The function of the PAN
parameter changes as follows, depending on the number of
input jacks that are currently turned on, and on the number
of recording tracks that are currently selected.
● When no recording track is selected
For the signal that is sent from the input mixer to the L/R
channels of the OUTPUT jacks, the PAN parameter will
adjust the panning position (if the input is in mono) or the
balance (if the input is in stereo).
● When a stereo track or two mono tracks are selected
as recording tracks
For the signal that is sent from the input mixer to the two
tracks, the PAN parameter will adjust the panning position
(if the input is in mono) or the balance (if the input is in
stereo).
● When one mono track is selected as recording track
The PAN parameter will have no effect.
Basic operation of the track
mixer
Adjusting the volume/pan/EQ
For each channel, you can adjust the volume, panning
(stereo position between L/R channels), and EQ (equalizer).
1.
To adjust the volume of a track or the drum/bass
sound, operate the respective fader.
2.
To adjust the panning position of a track or the
drum/bass sound, press the [PAN] key in the track
parameter section, and then press the status key
for the desired track or for the drum/bass sound.
A screen for adjusting the PAN parameter of the respective
track or drum/bass sound appears.
3.
Turn the dial to edit the value of the PAN parameter.
The PAN parameter can be adjusted in a range of L100 (far
left) - 0 (center) - R100 (far right).
To adjust the pan of another track or the drum/bass sound,
repeat steps 2 - 3.
H INT
• If a stereo track or the drum sound is selected, the PAN
parameter adjusts the left/right channel balance.
• In the parameter screen you can also use the cursor left/
right keys to select the track or drum/bass sound and the
cursor up/down keys to switch parameters.
4.
To adjust EQ, press the [EQ HIGH] or [EQ LOW] key
in the track parameter section.
Press the [EQ HIGH] key to adjust the high frequency range
tone, or the [EQ LOW] key to adjust the low frequency range
tone.
At this time, editing will affect the track or drum/bass sound
that was last selected. If necessary, switch to the desired
track or drum/bass sound.
0
TR1 TR1
PAN
PAN
