Reference [Mixer]
ZOOM MRS-1266
78
Adjusting the depth of the send/re-
turn effects
The depth of the send/return effects can be adjusted by
setting the volume (send level) of the signal that is sent from
the input mixer to each send/return effect (chorus/delay,
reverb). In normal operation, sending the signal from the
input mixer to the send/return effect will only apply the
effect to the signal that is sent from the OUTPUT jacks, and
will not affect the signal that is recorded on a track.
H INT
To record the signal processed by the send/return effect on
a track, you can use bounce recording while the respective
input [ON/OFF] key is on ( → p. 45).
1.
Press the [CHORUS/DELAY] key or [REVERB] key
to select a patch for the send/return effect.
The display changes and shows the currently selected patch
of the selected effect (chorus/delay or reverb).
2.
Turn the dial to select the patch you want to use.
When you have selected the patch, press the [EXIT] key.
3.
Press the [CHORUS/DELAY SEND] key or the
[REVERB SEND] key in the track parameter section
to select send/return effect.
Press the [CHORUS/DELAY SEND] key if you want to
adjust the chorus/delay send level or the [REVERB SEND]
key if you want to adjust the reverb send level.
For example, when the [CHORUS/DELAY SEND] key is
pressed, a screen such as shown below appears.
4.
Press the desired [ON/OFF] key in the input
section.
The input mixer (INPUT) is selected as target for setting the
send level.
5.
Turn the dial to select the effect depth.
Higher values result in more effect depth (stronger effect).
The range and default values for the parameters are shown
below.
● CHORUS/DELAY SEND: 0 - 100 (default: 0)
● REVERB SEND: 0 - 100 (default: 0)
H INT
• When the chorus/delay parameter is shown on the display,
pressing the [CHORUS/DELAY SEND] key will cause the
signal sent from the input mixer to chorus/delay to be
switched on/off. (The key will be out when this is off.)
• In the same way, when the reverb parameter is displayed,
pressing the [REVERB SEND] key will cause the signal
sent from the input mixer to reverb to be switched on/off.
6.
When you have finished making settings, press the
[EXIT] key.
The unit returns to the main screen.
Adjusting the pan/balance
This section explains how to adjust the pan (stereo position)
of the signal sent from the input mixer to the MASTER
OUTPUT jacks and the recording tracks, or the balance (the
volume balance between two channels).
1.
Press the [PAN] key in the track parameter section.
The screen for adjusting the PAN parameter appears.
2.
Press an [ON/OFF] key in the input section.
The input mixer will be selected for panning value
adjustment.
Parameter Setting value
0
TR1 TR1
CHO SEND
CHO SEND
0
INPUT INPUT
CHO SEND
CHO SEND
0
TR1 TR1
PAN
PAN
0
INPUT INPUT
PAN
PAN
