Appendix
ZOOM MRS-1266
169
DEPTH
RATE
COLOR
LowBoost
SIZE
FB
TIME
TONE
MIX
CLIP
SHIFT
BALANCE
FREQ
0 – 10
1 – 10
TYPE = FLANGER : -10 – 10
TYPE = DELAY : 0 – 10
TYPE = DELAY : 1 – 50
TYPE = DOUBLE : 1 – 100
1 – 100
0 – 10
0 – 30
0 – 10
-12.0 – 24.0
0 – 30
1 – 5
0 – 10
1 – 30
1 – 4
Specifies the depth of the effect.
Specifies the speed of the effect.
Modifies the type of phase tone.
Emphasizes the effect.
Specifies the amount of pitch shift produced by the pitch shifter.
Adjusts the balance between the direct sound and effect sound.
Specifies the frequency.
Emphasizes the low range.
Specifies the spatial width.
Adjusts the amount of feedback.
Sets the delay time. ( x 10 mSec )
Sets the delay time. ( x 1 mSec )
Sets the delay time. ( x 1 mSec )
Adjusts the tone.
Adjusts the mix amount of the effect.
Range Explanation of parameter Parameter name
Explanation of MODULATION/DELAY MODULE parameters
■ LINE ALGORITHM
A stereo input/output compressor.
A stereo input/output limiter.
PARAMETER 1 PARAMETER 2 PARAMETER 3 TYPE
COMP
LIMITER
ATTACK
RELEASE
SENS
THRSHOLD
LEVEL
LEVEL
COMP/LIM MODULE
Explanation of parameter
0 – 15
0 – 15
1 – 8
0 – 15
0 – 15
Specifies the input sensitivity of compression.
Adjusts the speed at which compression is applied.
Specifies the output level of the module.
Specifies the sensitivity at which the limiter will begin to apply.
Specifies the time from when the input signal falls below the threshold until compression ends.
Range Parameter name
SENS
ATTACK
LEVEL
THRSHOLD
RELEASE
Explanation of COMP/LIM MODULE parameters
Explanation of parameter
50 – 16000
50 – 16000
OFF, -24 – 6
OFF, -24 – 6
OFF, -24 – 6
Specifies the frequency at which the Lo/Mid bands will be divided.
Specifies the frequency at which the Mid/Hi bands will be divided.
Specifies the mix amount of the high range.
Specifies the mix amount of the mid range.
Specifies the mix amount of the low range.
Range Parameter name
XOVER_Lo
XOVER_Hi
MIX_HIGH
MIX_MID
MIX_LOW
Explanation of ISOLATOR MODULE parameters
An effect that divides the signal into three frequency bands, and lets you specify the mix amount.
PARAMETER 1 PARAMETER 2 PARAMETER 3 PARAMETER 4 PARAMETER 5 TYPE
ISOLATOR
XOVER_Lo XOVER_Hi MIX_HIGH MIX_MID MIX_LOW
ISOLATOR MODULE
*For an explanation of the parameters, refer to the GUITAR/BASS algorithm.
Three-band equalizer.
PARAMETER 1 PARAMETER 2 PARAMETER 3 PARAMETER 4 TYPE
3BandEQ
HIGH MID LOW LEVEL
EQ MODULE
Zoom's proprietary noise reduction that minimizes noise when you are not playing.
PARAMETER 1 TYPE
ZNR
THRSHOLD
ZNR MODULE
*For an explanation of the parameters, refer to the DUAL algorithm.
You can use an expression pedal to control the volume.
PARAMETER 1 TYPE
VOL PDL
MIN VOL
VOL PDL MODULE
*For an explanation of the parameters, refer to the DUAL algorithm.
