5.59 Processing Element Logical Layer Control CSR (PE_LL_CTL)
SRIO Registers
The processing element logical layer control CSR (PE_LL_CTL) is shown in Figure 122 and described in
Table 130 .
Figure 122. Processing Element Logical Layer Control CSR (PE_LL_CTL) - Address Offset 104Ch
31 16
Reserved
R-0
15 3 2 0
EXTENDED_
Reserved ADDRESSING_
CONTROL
R-0 R/W-001
LEGEND: R/W = Read/Write; R = Read only; -n = Value after reset
Table 130. Processing Element Logical Layer Control CSR (PE_LL_CTL) Field Descriptions
Bit Field Value Description
31–3 Reserved 0 These read-only bits return 0s when read.
2–0 EXTENDED_ADDRESSING_CONTROL Controls the number of address bits generated by the PE as a
source and processed by the PE as the target of an operation. All
other encodings reserved.
001b PE supports 34 bit addresses
010b PE supports 50 bit addresses
100b PE supports 66 bit addresses
Other Reserved
