Installing norstar telephones, Installing norstar telephones 198 – Nortel Networks 6.1 User Manual
Page 198
198
/ Telephone features
Compact ICS 6.1 System Coordinator Guide
P0603544 02
Installing Norstar telephones
If you are connecting a Norstar telephone for the first time, refer to the
illustrations below and use as a guideline.
Installing a Norstar telephone
Connect to
jack wired from
distribution block
Connect to
receiver
Connect to jack
wired from
distribution block
Connect to
receiver
