I/O Ports
15-60
15.13.3 Pin Configurations
Table 15-13-1 shows the pin configurations for port B.
Table 15-13-1 Port B Configuration
Port Pin PBn PBM = "1" PBM = "0"
No. PBnD = "1" PBnD = "0"
Port B 14 PB0 General-purpose General-purpose A8 Address output
output port input port > * 1 <
13 PB1 General-purpose General-purpose A9 Address output
output port input port <> * 1 <
12 PB2 General-purpose General-purpose A10 Address output
output port input port <> * 1 <
11 PB3 General-purpose General-purpose A11 Address output
output port input port <> * 1 <
10 PB4 General-purpose General-purpose A12 Address output
output port input port <> * 1 <
8 PB5 General-purpose General-purpose A13 Address output
output port input port <> * 1 <
7 PB6 General-purpose General-purpose A14 Address output
output port input port <> * 1 <
6 PB7 General-purpose General-purpose A15 Address output
output port input port <> * 1 <
[Note 1]
: When reset (whether in address/data separate mode or address/data multiplex mode)
*1 : In the event of a reset in address/data multiplex mode , the PBPU bit in the PBMD register is set to
"1" and the address/data pins (the 8 bits ADM[15:8]) are pulled up.
<<>> : These pins are set in address/data multiplex mode.
[Note 2]
When the bus authority is granted, A15 to A8 (ADM15 to ADM8) go to high impedance.
