Serial Interface
13-44
Serial 3 timer register
Register symbol: SC3TIM
Address:
x'3400083D
Purpose:
This register sets the timer that is used for internal division for serial interface 3.
Bit No.
7
6
5
4
3
2
1
0
Bit
–
SC3
SC3
SC3
SC3
SC3
SC3
SC3
name
TIM6 TIM5 TIM4 TIM3 TIM2 TIM1 TIM0
Reset
0
0
0
0
0
0
0
0
Access
R
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Set the value that corresponds to the required division ratio - 1.
