Interrupt Controller
9-27
Group 19 interrupt control register
Register symbol: G19ICR
Address: x'3400014C
Purpose: This register is used to enable group 19 interrupts, and to confirm interrupt requests and detection.
Bit No. 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit - G19 G19 G19 - - - AD - - - AD - - - AD
name LV2 LV1 LV0 IE IR ID
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Access R R/W R/W R/W R R R R/W R R R R/W R R R R/W
Bit No. Bit name Description
0 ADID A/D conversion end interrupt detection flag
0: No interrupt detected 1: Interrupt detected
3 to 1 — "0" is returned when these bits are read.
4 ADIR A/D conversion end interrupt request flag
0: No interrupt request 1: Interrupt request
7 to 5 — "0" is returned when these bits are read.
8 ADIE A/D conversion end interrupt enable flag
0: Disabled 1: Enabled
11 to 9 — "0" is returned when these bits are read.
12 G19LV0 Group 19 interrupt priority level register (LSB)
13 G19LV1 Group 19 interrupt priority level register
14 G19LV2 Group 19 interrupt priority level register (MSB)
Set a level from 6 to 0.
15 — "0" is returned when this bit is read.
