228
Set Command Library
Comments
d6
Air link speed (in baud):
PDL:
• 4800 (GMSK modulation)
• 9600 (GMSK or 4FSK modulation)
• 19200 (4FSK modulation)
MDL:
• 4800
• 7600
• 9600
ADL or XDL (12.5 kHz):
• 4800 (GMSK modulation)
• 8000 (GMSK modulation)
• 9600 (4FSK modulation)
ADL or XDL (25 kHz):
• 4800 (GMSK modulation)
• 9600 (GMSK modulation)
• 16000 (GMSK modulation)
• 19200 (4FSK modulation)
4800, 7600, 8000,
9600, 16000,
19200
s7 Radio sensitivity (PDL, ADL, XDL and MDL)
LOW, MED, HIG,
OFF
c8
Scrambler (PDL, ADL and XDL):
• 0: Off
• 1: On
0, 1
c9
Forward Error Correction (PDL, ADL and
XDL):
• 0: FEC Off
• 1: Hamming FEC On
0,1
s10
Transmission power for ADL Vantage:
• 0: 100 mW
• 1: 500 mW
• 2: 1 W
• 3: 2 W
• 4: 4 W
Transmission power for ADL Vantage Pro:
• 0: Level 1
• 1: Level 2
• 2: Level 3
• 3: Level 4
• 4: Level 5
See $PASHQ,RDP,PWR to set the power (in
Watts)
0-4
*cc Optional checksum *00-*FF
Parameter Description Range
