Spectra Precision ProMark 800 Reference Manual - Manual (Page 110)

98
Troubleshooting
Receiver is Not Tracking Satellites
202 Medium Invalid link speed
You are trying to set a baud rate that is not appropriate. Find which
baud rate should be used and try again.
203 Medium Invalid FEC mode
You are trying to set a FEC mode that is not appropriate. Check that
you are asking for a valid one.
204 Medium
Too many config files
(*.par)
The receiver is trying to use a configuration file but does not know
which one to use. Make sure there’s only one file available and it is the
one you want the receiver to use.
205 Medium
Invalid registration code =>
No registration code No registration code entered for the receiver. Contact Technical Sup-
port.
206 Medium
Invalid registration code =>
Bad registration code The receiver detects an incorrect registration code. Contact Technical
Support.
207 Medium
Invalid Position => Position
from $PASHS,POS The receiver detects an incorrect position assigned to its location. Use
$PASHS,POS to enter the right position.
208 Medium GSM already in FTP mode
You are trying to assign a function to the modem while it’s already
used in a network connection using the FTP protocol. See what you
want the modem to do and then take the necessary steps to use it as
desired.
209 Medium
ADL Radio Power is
reduced
The receiver detects that the radiated power level set in the radio used
was intentionally lowered. This is because the radio is powered from
the internal battery, not from an external power source.
210 Medium
Radio Protocol not sup-
ported You are trying to set a protocol that does not match the type of radio
used. Choose a suitable protocol and try again.
213 Medium
Bad Base Position => In
Rover mode, base position
received
The receiver detects a bad base position received from the base.
Check base position and correct it at the base.
214 Medium
Bad Base Position => In
Base mode, base position
sent
The receiver detects a bad base position assigned to the base. Check
base position and correct it.
215 Medium GNSS in Boot mode Contact Technical Support.
216 Medium ANP forbidden if HDB OFF
You are trying to enter a user-defined antenna while HDB is off. Set
HDB to on and try again.
217 Medium RCP forbidden if HDB OFF
You are trying to enter a user-defined antenna while HDB is off. Set
HDB to on and try again.
218 Medium Corrupted USB
A corrupted directory (“Found.*”) has been detected on the USB. The
key can still be used out of this directory. Re-formatting should be envi-
sioned.
219 Medium USB directory overflow
One directory has more than 500 files. The USB key is unmounted
automatically..
# Rank Alarm Label Symptoms & Remedies
RTK Base RTK Rover PP Base PP Rover
Relevant to • • • •
