Chapter 6. OPERATION
● Binary system
Handling Precautions
• When a program number of 0 is set using the external switch inputs,
programs can be selected using the console keys and by transmission.
• Program numbers 1 to 39 can be selected in the BCD system.
Status
Binary system
External switch number Weight
SW9 1
SW10 2
SW11 4
SW12 8
SW13 16
OFF ON ON OFF ON
OFF OFF ON OFF OFF
OFF OFF ON OFF OFF
OFF OFF ON OFF OFF
OFF
ON
ON
ON
ON
ON
OFF OFF ON ON
SW14 32 ON OFF ON ON ON ON
Number selection 32 31 ¥ ¥ ¥ 33 ¥ ¥ ¥ 47 48 49
Status
Binary system
External switch number Weight
SW9 1
SW10 2
SW11 4
SW12 8
SW13 16
OFF ON OFF ON ON OFF ON OFF ON
ON ON OFF OFF OFF ON ON OFF OFF
OFF OFF ON ON ON ON ON OFF OFF
OFF OFF OFF OFF ON ON ON OFF OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF OFF OFF OFF OFF OFF ON ON
SW14 32 OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
Number selection 2 1 0 3 4 5 ¥ ¥ ¥ 13 14 15 16 17
