● Writing into EEPROM
(1) Press SETUP key until the PROG/SEG display shows ( 02-09 ).
(2) Scroll ↑ , ↓ , ← , → , keys to show ( 1.1.1.1. ) on upper display.
(3) Press ENTER key .
■ Current output calibration
Scroll ↑ , ↓ , ← , → , keys to show ( 6.0.6.6. ) on the upper display, then press
ENTER key .
Connect the digital ammeter across terminals (See Figure 12-9).
● OUT CH1 output calibration
(1) Press SETUP key until the PROG/SEG display shows ( 06-01 ).
Scroll ↑ , ↓ , ← , → , keys until meter indicates 4.00mA, then press ENTER
key .
(2) Press SETUP key until the PROG/SEG display shows ( 06-02 ).
Scroll ↑ , ↓ , ← , → , keys until meter indicates 20.00mA, then press ENTER
key .
● OUT CH2 output calibration
(1) Press SETUP key until the PROG/SEG display shows ( 06-03 ).
Scroll ↑ , ↓ , ← , → , keys until meter indicates 4.00mA, then press ENTER
key .
(2) Press SETUP key until the PROG/SEG display shows ( 06-04 ).
Scroll ↑ , ↓ , ← , → , keys until meter indicates 20.00mA, then press ENTER
key .
● AUX CH1 output calibration
(1) Press SETUP key until the PROG/SEG display shows ( 06-05) .
Scroll ↑ , ↓ , ← , → , keys until meter indicates 4.00mA, then press ENTER
key .
(2) Press SETUP key until the PROG/SEG display shows ( 06-06 ).
Scroll ↑ , ↓ , ← , → , keys until meter indicates 20.00mA, then press ENTER
key .
● AUX CH2 output calibration
(1) Press SETUP key until the PROG/SEG display shows ( 06-07) .
Scroll ↑ , ↓ , ← , → , keys until meter indicates 4.00mA, then press ENTER
key .
(2) Press SETUP key until the PROG/SEG display shows ( 06-08 ).
Scroll ↑ , ↓ , ← , → , keys until meter indicates 20.00mA, then press ENTER
key .
Chapter 12. CALIBRATION
