The meaning of auxiliary setting 1 for special segment is shown below.
–2: Two segments before the final segment
1: First segment
–1: One segment before the final segment
2: Second segment
0: Final segment
*2:
When auxiliary setting 1 of RAMP-E time monitoring is set to 0.0 sec, event output is off.
*3:
Auxiliary setting 1 and auxiliary setting 2 of segment time and program time that determine display
unit and range of segment are set by setup data
C62
settings as follows.
When
C62
is set to 0: 0 hours 00 min to 500 hours 00 min
When
C62
is set to 1: 0 min 00 sec to 500 min 00 sec
When
C62
is set to 2: 0.0 sec to 3000.0 sec
Event type
130
132
133
131
Meaning
Message
READY, READY FAST,
READY, READY FAST
G.SOAK wait
G.SOAK
MANUAL
MANUAL
END
END
Range of auxiliary
setting 1
Message
Conditions assessed for each channel
0: only assigned channel
1: OR condition for both channels
2: AND conditions for both channels
Conditions assessed for each channel
0: only assigned channel
1: OR condition for both channels
2: AND conditions for both channels
Conditions assessed for each channel
0: only assigned channel
1: OR condition for both channels
2: AND conditions for both channels
Conditions assessed for each channel
0: only assigned channel
1: OR condition for both channels
2: AND conditions for both channels
Range of auxiliary
setting 2
Message
Unused
Unused
Unused
Unused
Setting category
Operation category
Instrument type
Mode type
Instrument type
Mode type
Instrument type
Mode type
Instrument type
Mode type
Event type
91
93
94
92
Meaning
Message
Segment number
BCD code
SEG-BCD
RAMP-E time monitoring
RAMP-E TIME OUT
Segment time
SEG TIME
Special segment
SEG SEQUENCE
Range of auxiliary
setting 1
Message
Number of output points
1 to 8
channels
Operating point
0.0 to 3000.0sec
*2
time out
On Time
0:00 to 500:00
*3
on-time
Segment specification
Ð2 to +2
*1
segment
Range of auxiliary
setting 2
Message
Unused
Unused
Off Time
0:00 to 500:00
*3
off-time
Unused
Setting category
Operation category
Instrument type
Code type
Instrument type
Time type
Instrument type
Time type
Instrument type
Mode type
Event type
95
128
129
96 to 127
Meaning
Message
Program time
PROG TIME
RUN, HOLD, END, FAST
RUN, HOLD, END, FAST
HOLD
HOLD
Event off
OFF
Range of auxiliary
setting 1
Message
On Time
0;00 to 500;00
*3
on-time
Conditions assessed for each channel
0: only assigned channel
1: ORcondition for both channels
2: AND conditions for both channels
Conditions assessed for each channel
0: only assigned channel
1: ORcondition for both channels
2: AND conditions for both channels
Unused
Range of auxiliary
setting 2
Message
Off Time
0:00 to 500:00
*3
off-time
Unused
Unused
Unused
Setting category
Operation category
Instrument type
Time type
Instrument type
Mode type
Instrument type
Mode type
Ð
