Honeywell DCP552 Mark II User Manual
Page 106
7-7
Item code
Item
No.
User
settings
Settings and descriptions
Factory default
settings
PA 47
Unused
47
[Description:]
Т-----У is displayed and setting can not be performed.
----
PA 48
Unused
48
----
PA 49
Unused
49
----
PA 50
Unused
50
----
PA 51
PV1 equalizer compensation
point No. 1
51
Compensation point No. 1
: PV1 range lower limit value (tied)
Compensation points No. 2 to 9 : Ð19999 to +20000 PVU (PV1)
Compensation point No. 10
: PV1 range upper limit value (tied)
Compensation amount No. 1 to 10: Ð1000 to +1000 PVU (PV1)
[Description:]
When setup data
C30
is set to 0, 2, Т-----У is displayed
and setting cannot be performed.
Compensation point No. 1 and No. 10 are automatically
changed during a PV1 range change.
Range lower
limit value
PA 52
PV1 equalizer compensation amount No. 1
52
0 PVU
PA 53
PV1 equalizer compensation point No. 2
53
500 PVU
PA 54
PV1 equalizer compensation amount No. 2
54
0 PVU
PA 55
PV1 equalizer compensation point No. 3
55
1000 PVU
PA 56
PV1 equalizer compensation amount No. 3
56
0 PVU
PA 57
PV1 equalizer compensation point No. 4
57
1500 PVU
PA 58
PV1 equalizer compensation amount No. 4
58
0 PVU
PA 59
PV1 equalizer compensation point No. 5
59
2000 PVU
PA 60
PV1 equalizer compensation amount No. 5
60
0 PVU
PA 61
PV1 equalizer compensation point No. 6
61
2500 PVU
PA 62
PV1 equalizer compensation amount No. 6
62
0 PVU
PA 63
PV1 equalizer compensation point No. 7
63
3000 PVU
PA 64
PV1 equalizer compensation amount No. 7
64
0 PVU
PA 65
PV1 equalizer compensation point No. 8
65
3500 PVU
PA 66
PV1 equalizer compensation amount No. 8
66
0 PVU
PA 67
PV1 equalizer compensation point No. 9
67
4000 PVU
PA 68
PV1 equalizer compensation amount No. 9
68
0 PVU
PA 69
PV1 equalizer compensation point No. 10
69
Range upper
limit value
PA 70
PV1 equalizer compensation amount No. 10
70
0 PVU
PA 71
PV2 equalizer compensation point No. 1
71
Compensation point No. 1
: PV2 range lower limit value (tied)
Compensation points No. 2 to 9 : Ð19999 to +20000 PVU (PV2)
Compensation point No. 10
: PV2 range upper limit value (tied)
Compensation amount No. 1 to 10 : Ð1000 to +1000 PVU (PV2)
[Description:]
When setup data
C30
is set to 0, 1, Т-----У is displayed
and setting cannot be performed.
Compensation point No. 1 and No. 10 are automatically
changed during a PV2 range change.
Range lower
limit value
PA 72
PV2 equalizer compensation amount No. 1
72
0 PVU
PA 73
PV2 equalizer compensation point No. 2
73
500 PVU
PA 74
PV2 equalizer compensation amount No. 2
74
0 PVU
PA 75
PV2 equalizer compensation point No. 3
75
1000 PVU
PA 76
PV2 equalizer compensation amount No. 3
76
0 PVU
PA 77
PV2 equalizer compensation point No. 4
77
1500 PVU
PA 78
PV2 equalizer compensation amount No. 4
78
0 PVU
PA 79
PV2 equalizer compensation point No. 5
79
2000 PVU
PA 80
PV2 equalizer compensation amount No. 5
80
0 PVU
PA 81
PV2 equalizer compensation point No. 6
81
2500 PVU
PA 82
PV2 equalizer compensation amount No. 6
82
0 PVU
PA 83
PV2 equalizer compensation point No. 7
83
3000 PVU
PA 84
PV2 equalizer compensation amount No. 7
84
0 PVU
PA 85
PV2 equalizer compensation point No. 8
85
3500 PVU
PA 86
PV2 equalizer compensation amount No. 8
86
0 PVU
PA 87
PV2 equalizer compensation point No. 9
87
4000 PVU
PA 88
PV2 equalizer compensation amount No. 9
88
0 PVU
PA 89
PV2 equalizer compensation point No. 10
89
4500 PVU
PA 90
PV2 equalizer compensation amount No. 10
90
0 PVU
PA 91
Unused
91
-----
PA 92
Unused
92
-----
[Description:]
Ò-----Óis displayed and setting cannot be performed.
Chapter 7. PARAMETER SETUP
